10,000 Liter Flexible Gas Storage Bag
Compact • Safe • Ideal for Pilot & Small Biogas Applications
The 10000 Liter Flexible Gas Storage Bag is a compact, low-pressure gas holder designed for small-scale biogas systems, pilot projects, laboratory testing, and demonstration units. Manufactured using high-quality PVC-coated polyester fabric, it provides reliable gas storage with minimal installation and maintenance requirements.
Key Features
- Low-pressure biogas storage (2–5 mbar)
- Flexible, lightweight, and easy to transport
- Gas-tight welded construction
- Suitable for indoor and outdoor use
- Customizable inlet and outlet connections
Technical Specifications
| Parameter | Specification |
| Storage Capacity | 1000 Liters (1.0 m³) |
| Working Gas | Biogas / Low-pressure gas |
| Working Pressure | 2 – 5 mbar |
| Maximum Design Pressure | 8 – 10 mbar |
| Approx. Dimensions | ~1.2 m × 1.0 m × 0.9 m |
| Membrane Material | PVC-coated polyester fabric |
| Membrane Weight | 650 – 900 g/m² |
| Membrane Thickness | 0.6 – 0.8 mm |
| Gas Inlet / Outlet | ½” or ¾” BSP / hose connection |
| Operating Temperature | 0 °C to +40 °C |
| Fabrication | Locally fabricated in Pakistan |
Typical Applications
- Small biogas digesters
- Pilot and demonstration biogas plants
- Laboratory gas testing
Optional Accessories
- Pressure gauge (mbar range)
- Manual shut-off valve
- Condensate drain point
- Carrying handles or lifting loops
